Biotechnology
Infrastructure Facility
I. Major Equipments Available
Sl. No. |
Major Equipments Available | Brief Specification | Quantity |
|---|---|---|---|
1 |
Binary HPLC | • Shimadzu LC-20A Binary Gradient System • LC 20AD Solvent Delivery Unit • Automatic Rinsing Kit • Gradient Mixer SUS 20 A • UV Vis Director • Lab Solution LC Work station Single software. |
1 |
2 |
Laminar Airflow (Vertical and Horizontal) | • Main body: Made of good quality MS duly powder coated finish • Working zone: Made of stainless steel and removable for cleaning • Working area: 3ft x 2ft x 2ft. • Accessories: spill Trough or drainage (SS), static pressure gauge, UV light, fluorescent lighting, valve for Gas/air, electric socket for plugging lab instrument, sliding door (polycarbonate) and bar rod or hook for pipettes should be provided with the cabinet. • The cabinet’s airflow is 100% exhausted • Air Filters: HEPA Filters 99.99% at 0.3 Microns Efficiency |
2 |
3 |
PCR | • Palm cycler: Cool gradient • Sample capacity: 96 x 0.2ml • Temperature:4-990C |
1 |
4 |
UV- Spectrophotometer | • Measurement modes: % REL and % TRN • Measurement principle: Dual Beam • Sphere dimension: 150 mm • Light source: Xenon • Wavelength range: 190 – 1100 nm • Wavelength interval: 10 nm • Wavelength accuracy: ± 0.1 nm • Repeatability: ≤ 0.5 nm • Measurement time: Within 2 seconds • Band width: 1 nm • Scan Speed: Up to 4000 nm/ min • Scanning Range: Full range scanning • Display: Graphical with LCD back light |
1 |
5 |
Gel Documentation unit | • MS-Designed Imager software with PC • Camera Type-CMOS Scientific • Sensor-5M Pixel Monochrome • Max. CMOS Resolution-2592 x 1944 pixel • Pixel Density-RAW 8 bit /10bit/ 12 bit • Lens-6mm, F 1.2 • Filter –Etbr filter • Power-DC5V / 250mA • Display-1280 x 800 Resolution • UV Trans-illuminator • Filter Size-21 x 26 cm • Safety Device- Automatic UV light shut-off when door open |
1 |
6 |
Ultra Sonicator | • Input Voltage-230 Vac @ 50/60 Hz • Full Lad Current-700 mA • Fuse Rating -2 Amps (GDB8)* • Weight-16.5 Ibs (7.4Kg) • Dimensions: 282 cm x 255cm x 102 cm • Output Voltage: 1200 V rms (max). • Output Frequency: 20 KHz (nom.) |
1 |
7 |
Lyophilizer | • Ice Capacity in 12 hours:1.2Kg • Ice capacity in 24 hours:2.3 Kg • Maximum ice capacity : 5.0Kg • Max. Temp. : -08(± 50C) @ 200 ambient • Surface area: 0.15 Sq. m • Volume: 7.2 Ltrs • Temp. gauge: Digital RTD • Vacuum gauge: Digital Rirani |
1 |
8 |
ELISA Reader | • Voltage: 100-250 VAC • Weight: 2.6Kg • Frequency: 50/60 Hz • Measurement Range:0-4.0 OD |
1 |
9 |
Orbital Shaking Incubator | • TEMP. CONTROLLING • Temp. Range ambient +5°C. to 50°C. • Temp. Controller using PT-100 sensor. • Max speed: 250 RPM • Temp. Time and set RPM Display: • LED with Alarm facility • Shaking platform: 500 ml capacity 16flask • Double door • Interior Chamber: SS made |
1 |
10 |
Cooling Centrifuge (Eltek) | • Max. Speed- 20000 RPM • Time – 1 to 99 minutes • Max. RCF – 34500g • Temp= -100C to 400C • Display- LCD set and working Parameters • Memory 25 programs • 48 x 2/1.5ml Angle Rotor Head with Lid |
1 |
11 |
Fermentor | • Fermetation Jacket (Autoclavable): 5L capacity • pH and PO2 probes • Display: LED • Autoclave • SCADA software |
1 |
12 |
Cross flow Cassettes | • Product Length: 450 x 205 x 480 mm • Product weight: 10kg • Mains Power: 230V, 50Hz, single phase • Inlet pressure: 0.3 to 1 bar • Outlet pressure: 1.8 bar (set pressure) |
1 |
13 |
Kjadahls Apparatus | • Digestion Unit: Test tube size of 625ml 6 set • Temperature: 6500C • Automated Sodium hydroxide addition • Scrubber to absorb fumes • Power: 1600W • Automatic distillation (Sodium hydroxide) • Digital tube • Inbuilt Vapodest software pc compatibility |
1 |
14 |
Dietary Fiber Analyser | • Enzymatic Digestion Unit • Multi point magnetic stirrer adjustable rpm (50-850rpm) • Stirring volume Max 400ml • Temperature range RT +5-1000C with temperature controller • Safety thermostat • Power: 230V/50-60Hz • Filtration Unit: Epoxy painted S/S • Peristaltic pump with high suction capacity • Flask Volume: Max 1000ml |
1 |
15 |
Texture Analyser | • Load Range: 1 to 50 KG • Load Resolution: 4 to 6 gram Test • Speed Range: 0.01MM/S to 8MM/S • Test speed accuracy: Better than 0.1% of full scale range • Load Accuracy: Better than ± 0.5% to full scale range • Test modes: Single, Hold, Repeat, Cycle • Compression Data Acquisition Minimum 20 sets per second • Software: Texture Analyzer software • Fixture base table attachment • Force capacity: 10-50 Kg. f • Force resolution: 0.1 g • Load cell: 5,30,50,100 Kg. f |
1 |
16 |
Pilot Scale Spray Dryer | • Suitability: Aqueous, Aqueous + Solvents, Solvent feeds / emulsion / Cream past
suspension • Evaporation rate: Minimum 1000 ml of water evaporation/hr • Drying temperature: Ambient to 350 ± 10 C • Diameter of inside drying chamber:0.360 mm minimum • Length of the drying chamber: 0.90 m minimum • Air heater capacity: 2 kW minimum • Aspirator (Blower capacity): 0.20 HP X 4000 rpm • Blower motor:180 Watts x 12 Volt DC + • Feed pump capacity: 0-30 rpm with 3 mm ID tube- controlled through microprocessor • Feed pump flow rate: 100 ml/hr minimum • Compressed air for 2 fluid nozzle 2-4 bar • Dimensions of the equipment Minimum 650 mm X 630 mm X 900 mm • Body Material Stainless Steel and Glass can be used for visualization • The unit should contain: Feed tank automiser peristaltic pump sprayer chamber, cyclone separator, collector air heating system • Unit: stainless steel supporting stand |
1 |
17 |
Bomb Calorimeter | • Automatic microprocessor controlled and • Auto gas filling • Samples: Crushed, powdered, polymers, composites, liquids, solid and liquid fuels, food samples • Repeatability:1% • Measurement precision: .1% RSD • Pellet press Punch and dye set • DNG Software |
1 |
18 |
Viscometer | • Viscosity Range: Minimum 200++ Maximum 80M • Speed: :0.1 to 250 RPM • Display : LCD • Built in power: Math modeling temperature control yield test programmable QC alarms. • Accuracy: ± 1% • Repeatability: ± 0.5% |
1 |
19 |
Rotary Vacuum Flash Evaporator | • Heating bath dimensions: 230 X 130 mm • Volume of heating bath: 4 Litre Approx. • Heating bath controller: PID with display • Heating temperature range :Ambient to 1800 C Temperature accuracy : ± 20 C • Flask size: Different size glass flasks (1000 ml to 3000ml) • Rotational speed: 0 to 280 rpm • Heat adjustment: 240 mm Approx • Display: Digital |
1 |
20 |
Digital Refractometer | • Measuring range: 0.0 to 95 % Brix • Temperature range:0-800C • Battery life :Approx 5000 readings • Auto off: After 3 mins • Accuracy: ± 0.1 % Brix • Resolution: 0.1 % Brix • Minimum samples Volume:100 µl (to cover the prism totally) • Display: LCD |
1 |
21 |
Bernoulli’s Theorem Apparatus | To investigate validity of Bernoulli’s equation and when it is applied to study state flow of water through various flow meters | 1 |
22 |
Pressure drop in Packed bed column | To find the effect of superficial mass velocity on a pressure drop across the packed bed with liquid flow and verify Erguns equation | 1 |
23 |
Leaf Filter | Leaf diameter:0.1m Filtration Chamber Diameter: 0.084m | 1 |
24 |
Interacting System | • Tank Dimension: SS Tank, 300 x 250 x
300mm • Sump Tank: 700 x 500 x 300 mm • Capacity: 105 Liter • Pump: 0.5HP • Rotometer: 3-30LPM |
1 |
25 |
Non interacting System | • Tank Dimension: SS Tank, 300 x 250 x
300mm • Sump Tank: 700 x 500 x 300 mm • Capacity: 105 Liter • Pump: 0.5HP • Rotometer: 3-30LPM |
1 |
II. Software’s Available
Sl. No. |
Name | Type (System/ Application) |
|---|---|---|
1 |
GCG (Genetic Computing Group) for Bioinformatics Lab | Application |
2 |
SCADA Software for Fermentor | Application |
3 |
Magnus Pro Image Processor for Camera Attached Microscope | Application |
4 |
Innovative Life Sciences Software for Gel Documentation | Application |
5 |
Lab Solutions Software for HPLC | Application |
6 |
Empower Software for HPLC | Application |
7 |
Win 7, Win 8.1, Win 10 Professional N | System |
